DQOR® SUB 8 D Powered Dante Indoor/Outdoor Installation Subwoofer, black

Item No.: LDDQORSUB8D
Series: DQOR
Versions:
8" Powered Subwoofer with 10" passive radiator
190 W RMS subwoofer power
2 channel Dante audio connection
Clean, low-profile design with robust aluminium enclosure
Optional Surface Mount bracket (wall + ceiling) with hinges for easy installation
IP55 rated for outdoor use


Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results
8" Powered Subwoofer with 10" passive radiator
190 W RMS subwoofer power
2 channel Dante audio connection
Clean, low-profile design with robust aluminium enclosure
Optional Surface Mount bracket (wall + ceiling) with hinges for easy installation
IP55 rated for outdoor use
Description

Part of the DQOR® series, the DQOR® SUB 8 D is a powered installation indoor/outdoor subwoofer with an 8" woofer and a 10" passive radiator. With a built in Dante audio connection, it easily connects to any networked audio system and is AES67 compliant for compatibility with thousands of audio devices.

Designed for high performance in a compact form factor, it delivers powerful bass audio with no need for separate amplifier racks.

Uniquely the DQOR® SUB 8 D is the only outdoor rated Dante sub bass loudspeaker available.

The clean and low-profile design ensures the DQOR® SUB 8 D is a sleek addition to any room, combining aesthetics with powerful audio performance. Rated at 190 W RMS and max power of 230 W, it delivers impressive sound quality at up to 108 dB SPL with low frequency extension down to 37 Hz.

The DQOR® SUB 8 D has rubber feet for floor mounting, or it can be easily installed with the optional surface mount bracket, which includes flexible mounting options, holes for clean cable management, locking screws, a safety-locking mechanism, and a hinge mechanism for quick setup.

AC inputs are connected with a 3-pole phoenix contact terminal block with lever push-in connector for reliable and safe connection of the power cables. Terminal block connectors allow for remote standby control.

The DQOR® SUB 8 D can be used in a wide variety of applications both inside and outside including hospitality, retail, entertainment, or corporate settings.

It is available in black or white (RAL9005 & RAL9016).

Specifications
General
Directivity
Omnidirectional
Peak output power
230 W
RMS output power
190 W
Amp class
Class D
SPL (1 W/1 m)
86 dB
Max. SPL peak (sine burst, halfspace/1 m, THD≤10 %)
110 dB
Max. SPL peak (pink noise, halfspace/1 m, CF 4)
119 dB
Crossover frequency
110 Hz
Protection features
Short circuit, Overheating, Overvoltage, Undervoltage, Direct current
Colour
Black
RAL code
RAL 9005
Inputs
Number of Dante® inputs
1
Dante® connector type
RJ-45 socket
Dante®
Channel configurations
Stereo (2 channels)
Max. channels (44.1 kHz/48 kHz)
2
Sample rate
48 kHz
Bit depth
24 Bit, 32 Bit
Signal processing
AD/DA converter bit depth
24 Bit
AD/DA converter sampling rate
48 kHz
Min. Signal-to-noise ratio (SNR)
96 dB
System latency
2 ms
Amplifier
Sub output power per channel (RMS)
190 W
Sub output power per channel (Peak)
230 W
External control
GPI controllable functions
Standby
GPI input connection socket
Terminal block 2 pin (Euroblock) / 3.81 mm pitch
Bass driver
Size
8 "
Magnet
Ferrite
Voice coil
2.5 "
Passive radiator
10 "
Mains operation
Operation voltage
100 V AC - 240 V AC (±10 %) / 50 - 60 Hz
Power supply type
Switched-mode power supply (SMPS)
Rated power
270 W
Power consumption in idle mode
18 W
Max. Stand-by power consumption
2 W
Inrush current
2.4 A
Mains fuse
T3.15AL/250 V
Fuse replacement
Possible from the outside without opening
Standby
Auto standby after
20 min
Standby wake up time
3 s
Housing
Design
Closed with passive radiator
Chassis material
Die-cast aluminium, Plastic
Front grille material
Aluminium
Cooling
Cooling system
Convection cooling
Environmental
Ambient temperature
-10 - 50 °C
Maximum air humidity (non-condensing)
85 %
Safety Class
Class 1
Dimensions & weight
Width
537.4 mm
Height
304.4 mm
Depth
208.1 mm
Weight
15.2 kg
