4 SOUND PRESETS & 3-BAND EQ
The four intuitively operated sound presets and the 3-band EQ enable quick, user-friendly sound adjustment
The latest generation of LD Systems’ proprietary DynX DSP guarantees a dynamic, high-resolution sound image across the entire frequency response.
The highly effi cient Class D power amp delivers 300 watts RMS. The peak power of 1200 watts, which can be called up at short notice, guarantees a dynamic, assertive sound image.
Our engineering team put great care in creating an intuitive user-panel with just the controls and inputs you really need.
The next monitor can be supplied with power via a second PowerCon compatible connection. Thanks to the two XLR outputs, you can also daisy chain the audio signal to a neighbouring stage monitor.
The enclosures are made of heavy-duty 15 mm birch plywood and coated with particularly resistant polyurea. Thus, they reliably withstand many years of hard use „on the road“.
The extra-strong, torsion-resistant steel grilles effectively protect the speakers.
The two cast aluminium handles, homogeneously integrated into the overall appearance, enable the best possible handling on stage.
The connections and controllers are recessed in steel trays and are thus optimally protected against damage.
An elegantly designed heat sink on the back of the monitor provides fanless and thus noiseless cooling of the power electronics
The MON 15 A G3 is part of an entirely newly developed family of powered stage monitors for high performance. The MON G3 Series incorporates the advanced technology and premium materials found in high-end monitors typically rented by professionals, making this quality available to everyone. These include, for example, advanced coaxial loudspeakers with integrated 50° x 90° CD horn, which ensure the acoustic ideal of a true point source and thus outstanding audio characteristics even at short listening distances. Besides this, the series offers a high-level of robustness, a comprehensive set of features and the elegant LD Systems design.
A maximum sound pressure level of 129 dB and superior bass reproduction make the MON 15 A G3 the best choice for loud band stages, as a drum fill or for stand-alone use as a compact front PA without an additional subwoofer. For a 15" stage monitor, it is unusually compact and elegant, so despite its impressive performance data, it blends harmoniously into the stage set.
Both the signal (XLR/jack combo) and the power connection (PowerCON compatible) can be looped through. This allows for elegant, tidy cabling in multi-monitor set-ups or for distributed sound reinforcement.
|Product type||Stage monitors|
|System output (RMS)||300 W|
|System output (Peak)||1200 W|
|Max. SPL Average (Sine burst)||122 dB (100 Hz - 12 kHz, fullspace @1m, 10% THD)|
|Max. SPL Peak (Sine burst)||129 dB (fullspace @1m, 10% THD)|
|Frequency response (-3 dB)||58 - 18000 HZ|
|Frequency response (-10 dB)||48 - 20000 Hz|
|Crossover frequency||1300 Hz|
|Dispersion (H x V)||50° x 90°|
|Features||3-band EQ (High, Mid, Low), Delay line, Notch filter|
|Low/mid Woofer dimensions||15 "|
|Woofer dimensions (mm)||381 mm|
|Woofer type||Coaxial loudspeaker|
|Woofer voice coil||3 "|
|Woofer voice coil (mm)||75 mm|
|Cabinet construction||Bass Reflex|
|Cabinet material||15 mm Birch Plywood, 15 mm MDF|
|Tweeter dimensions||1 "|
|Tweeter dimensions (mm)||25.4 mm|
|Tweeter voice coil||1.75 "|
|Tweeter voice coil (mm)||44.45 mm|
|Protection circuits||Multiband limiter, over voltage, over-current, thermal overload|
|Operating Temperature||0 - 40 °C|
|Humidity Range||< 80 % ( non-condensing )|
|Fuse||T4AL 250 V|
|Controls||On / off switch, Rotary/push encoder|
|Operating voltage||100 V AC - 240 V AC, 50 - 60 Hz|
|Power consumption||150 W|
|Power in / out||PowerCON compatible|
|Line input connectors||6.3 mm jack, XLR - combo|
|Line through connector||XLR|
