MAUI® 44 G3 SUB W

Name: MAUI® 44 G3 SUB W
SKU: LDM44G3SUBW

Active 15" extension subwoofer for MAUI® 44 G3 W, White

Article number: LDM44G3SUBWItem No. LDM44G3SUBW

2 Photos ,

New

MAUI® 44 G3 SUB W

Active 15" extension subwoofer for MAUI® 44 G3 W, White

Model:

Article number: LDM44G3SUBWItem No. LDM44G3SUBW

15" high-power bass reflex subwoofer with low-end down to 34 Hz
Designed to complement the MAUI® 44 G3 W, with a dedicated preset for cardioid subwoofer setups
Airflow-optimised bass reflex design for extended low-frequency response and reduced port noise
DynX® DSP (Gen.2) with advanced limiters for distortion-free sound even at maximum volume
Rugged birch plywood cabinet with a durable polyurea coating
Shockproof front grille for ultimate speaker protection
Four ergonomic carrying handles for easy transport and positioning

More Features

Description

Features

15" high-power bass reflex subwoofer with low-end down to 34 Hz
Designed to complement the MAUI® 44 G3 W, with a dedicated preset for cardioid subwoofer setups
Airflow-optimised bass reflex design for extended low-frequency response and reduced port noise
DynX® DSP (Gen.2) with advanced limiters for distortion-free sound even at maximum volume
Rugged birch plywood cabinet with a durable polyurea coating
Shockproof front grille for ultimate speaker protection
Four ergonomic carrying handles for easy transport and positioning

The MAUI® 44 G3 SUB W is the extension subwoofer for your MAUI® 44 G3 W, providing additional bass output or enabling a cardioid subwoofer configuration.

More bass for your crowd

To achieve this, position the MAUI® 44 G3 SUB W facing forwards alongside your MAUI® system, leaving the cardioid preset deactivated. This gives your sound an even more powerful low-end foundation.

Controlled bass on stage

To create a cardioid subwoofer setup, position the additional subwoofer facing backwards next to your MAUI® 44 G3 W and activate the cardioid preset. Working together with the system's subwoofer, this setup significantly reduces bass radiation behind the system while reinforcing bass towards the audience.

Quick and easy setup

With no column inserted, the MAUI® 44 G3 SUB W automatically switches to FOLLOWER mode. To add the subwoofer to your system, simply connect the Sub-Out of your MAUI® 44 G3 W or the System-Out of your MAUI® 44 G3 W to the right input (R) of the FOLLOWER subwoofer using an XLR cable.

Specifications

Search by detail: e.g. RMS... (Optional)

Type (active/passive)	Active
Peak output power	3600 W
RMS output power	1800 W
Amp class	Class D
SysLink®	No
Max. SPL peak	133 dB
Low frequency limit (-6 dB, rel. Avg.)	34 Hz
Low frequency limit (-10 dB, rel. Avg.)	37 Hz
Crossover frequency	200 Hz
Number of inputs	2
Input connector types	XLR combo socket
Number of outputs	3
Output connector types	XLR 3-pole male
Protection features	Limiter, Overheating
Colour	White
