MAUI® 66 G3 SUB W

Active 18" extension subwoofer for MAUI® 66 G3 W, White

MAUI® 66 G3 SUB W-1
MAUI® 66 G3 SUB W-2
MAUI® 66 G3 SUB W-3
2 Photos ,
New

MAUI® 66 G3 SUB W

Active 18" extension subwoofer for MAUI® 66 G3 W, White

Model:
Share
Article number: LDM66G3SUBWItem No. LDM66G3SUBW
  • 18" high-power bass reflex subwoofer with low-end down to 28 Hz
  • Designed to complement the MAUI® 66 G3 W, with a dedicated preset for cardioid subwoofer setups
  • Airflow-optimised bass reflex design for extended low-frequency response and reduced port noise
  • DynX® DSP (Gen.2) with advanced limiters for distortion-free sound even at maximum volume
  • Rugged birch plywood cabinet with a durable polyurea coating
  • Shockproof front grille for ultimate speaker protection
  • Four ergonomic carrying handles for easy transport and positioning
More Features

Description

Features
  • 18" high-power bass reflex subwoofer with low-end down to 28 Hz
  • Designed to complement the MAUI® 66 G3 W, with a dedicated preset for cardioid subwoofer setups
  • Airflow-optimised bass reflex design for extended low-frequency response and reduced port noise
  • DynX® DSP (Gen.2) with advanced limiters for distortion-free sound even at maximum volume
  • Rugged birch plywood cabinet with a durable polyurea coating
  • Shockproof front grille for ultimate speaker protection
  • Four ergonomic carrying handles for easy transport and positioning

The MAUI® 66 G3 SUB W is the extension subwoofer for your MAUI® 66 G3 W, providing additional bass output or enabling a cardioid subwoofer configuration.

More bass for your crowd

To achieve this, position the MAUI® 66 G3 SUB W facing forwards alongside your MAUI® system, leaving the cardioid preset deactivated. This gives your sound an even more powerful low-end foundation.

Controlled bass on stage

To create a cardioid subwoofer setup, position the additional subwoofer facing backwards next to your MAUI® 66 G3 W and activate the cardioid preset. Working together with the system's subwoofer, this setup significantly reduces bass radiation behind the system while reinforcing bass towards the audience.

Quick and easy setup

With no column inserted, the MAUI® 66 G3 SUB W automatically switches to FOLLOWER mode. To add the subwoofer to your system, simply connect the Sub-Out of your MAUI® 66 G3 W or the System-Out of your MAUI® 66 G3 W to the right input (R) of the FOLLOWER subwoofer using an XLR cable.

Specifications

Type (active/passive)Active
Peak output power3800 W
RMS output power1900 W
Amp classClass D
Max. SPL peak135 dB
Low frequency limit (-6 dB, rel. Avg.)33 Hz
Low frequency limit (-10 dB, rel. Avg.)28 Hz
Crossover frequency200 Hz
Number of inputs2
Input connector typesXLR combo socket
Number of outputs3
Output connector typesXLR 3-pole male
ColourWhite

Downloads

REACh Declaration
Adam Hall GmbH|141 KB
INTERNATIONAL
RoHS Confirmation
Adam Hall GmbH|203.79 KB
INTERNATIONAL
Catalogue / Brochure
AHG Product Highlights Autumn Winter 2026/27|12.93 MB
EN
Catalogue / Brochure
Highlight Brochure DJ & Musician|5.87 MB
EN
Catalogue / Brochure
Highlight Broschüre Integrated DE 06/26|18.62 MB
DE
Catalogue / Brochure
LD Systems Highlight Brochure|5.87 MB
EN

Videos

Accessories

New
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
Product image of MAUI® 66 G3 SUB CB
MAUI® G3 Series

MAUI® 66 G3 SUB CB

Castor board for MAUI 66 G3 subwoofer

  • Material: Birch multiplex
  • Coating: Polyurea
  • Colour: Black
Learn more
New
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
Product image of MAUI® 66 G3 SUB PC
MAUI® G3 Series

MAUI® 66 G3 SUB PC

Padded protective cover for MAUI 66 G3 subwoofer

  • Water-repellent: Yes
  • With shoulder strap: No
  • Closure type: YKK zipper
Learn more
